In-line centrifugal pumps stainless steel



Stainless steel and SS2378 SMO

Stainless steel inline centrifugal pumps equipped with flange connections. Acid-resistant dry motor pump with a highly energy-efficient and reliable structure. The bearings of the electric motors are permanently lubricated and maintenance-free.

Stainless steel fixed speed pumps are suitable for closed and open systems, refrigeration circuits and industrial systems, as well as water distribution. Stainless steel centrifugal pumps can be used as circulation, pressure boosting and transfer pumps for acid and alkaline liquids.

技术数据

Models

AKNH, ALH, ALM, ALS, ALX, LH, LS, LX

Material

Duplex A890 Grade 3A and SuperDuplex 5A890 Grade 5A, 254 SMO, Stainless steel AISI 316

Maximum pump head

100m

Liquid temperature range

-25 … +180°C

Motor power range

0,05 – 160 kW

应用

Domestic water, Industrial systems, Open systems, Pressure rise

Liquids

Hot and cold oxygenated water, Chlorinated water, Sea water, Alcoholic solutions, Other heat transfer fluids

Nominal pressure

PN16
